Digital Refractor Phoropter

Basic Information
Place of Origin: Zhengzhou
Brand Name: NANBEI
Certification: CE,ISO,SGS
Model Number: NB-Z3000
Minimum Order Quantity: 1 set
Packaging Details: Wooden case
Delivery Time: 7 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 SET PER MONTH
Detail Information
Cross Cylinder: ±25 Diopters Cross-cylinder Lens: ±0.25D
Net Dimensions: 345×295×85(mm) Net Weight: Approx.4.5Kg
Package Dimensions: 380×350×155(mm) Gross Weight: 6Kg
High Light:

Digital Refractor Phoropter


optometry Refractor Phoropter


Ophthalmic Refractor Phoropter

Product Description

● Sphere power

Range:+16.75 to -19.00D


● Cylinder power

Range:0.00D to -6.00D

( 0.00D to 8.00D with additional lens of-2.00D)


● Cylinder axis 0 to 180°,5°steps
● Cross Cylinder ±25 diopters
● Cross-cylinder lens ±0.25D
● Rotary prisms 0△ to 20△,1△ steps
● Auxiliary lens dial

[O]-Open aperture (two positions).

[R]-Retinoscopic lens,+1.50D.

[P]-Polarizing lens,(45°left eye,135°right eye).

[WMV]or[RMV]-Maddox rod,vertical.

white — left eye.

Red — right eye.

[WMH]or[RMH]-Maddox rod,horizontal.

white - left eye.

Red - right eye.

[GL]- Green Lens.

[RL]-red Lens.

[+.12]- +0.12D Sphere.

[PH]- Pin hole.

[10△I]or [6△U]-10△ base-in-left eye.

6△ base-up-right eye (Dissociating prisms).

[±.50]-±0.50 fixed cross cyliner.

[OC]- Occluder.


● P.D.adjustment 48-75mm,1mm steps
● Standard Accessory One near point card with holder and rod,dust cover,face shield and case for lenses.
● Standard Accessory lens Two-.12D and -2.00 cylinder lenses. Two plano lenses for sealing front opening
● Net Dimensions 345×295×85(mm)
● Net weight Approx.4.5Kg
● Package Dimensions 380×350×155(mm)
● Gross weight 6Kg



The comprehensive refractor first appeared as an instrument to check the function of the extraocular muscles. It checks the concentration of light after entering the eyeball. It uses the state of the emmetropia as the standard to measure the difference in vergence and dispersion between the inspected eye and the emmetropia.Digital Refractor Phoropter 0
