LCD display Mercury Analyzer for gasous trace mercury measurement
Brief introduction of Mercury Analyzer :
201G Protable Mercury Analyzer is the perfessional measuring instrument which used for testing air mercury.It’s easy to carry with compact size,mainly used for testing various mercury contents in air,also used in Labortary. Using “Cool steam” method to test mercury content in drinking water,natural water and waste water,water sample need digestion preprocessing. Use Gold membrane theory to test mercury in air directly,suitable for environmental air mercury test,also used for mercury detection in fluorescent lamp factory,energy saving lamp producing department where including mercury and other easy volatility impurity gas.Also used in geology, petroleum, seismic system mercury vapor gas field soil sample analysis.Measurement data can be read through the LCD display,also can be saved in text format in the host, you can always adjust the number of connections to the computer.
Features of Mercury Analyzer:
1.Testing of gaseous mercury concentrations in samples no longer need to use potassium permanganate adsorption after reduction, direct sampling measurements in the field test
2.Because battery powered, the instrument can be brought to the field where no power supply, the instrument itself weighs only 4.8kg, very convenient to carry
3.Provided lithium battery-powered, the battery can work for 8 hours, weighs only 2.8kg. If every time out for a short time, you can choose a smaller-capacity lithium battery, its weight is also more compact.
4.Operated by the MCU control, only the key to complete all the work
- gaseous mercury Hg0
|
| Measuring principle |
Gold amalgam,Atomic absorption spectrometry |
| Detection limit |
0.001μg/m3 |
| Measure range |
0.003~100μg/ m3 |
| Repeatability |
≤5% |
| Air flow |
0.1-1.2L/min |
| Weight |
4.8kg |
| Dimension |
370×220×150(mm) |
Optional accessories
1. Notebook computers and software
2. Battery: Lithium battery (optional, suitable for field work continuously 8 hours)
3. QMF1 soil gas samplers, geology, petroleum, seismic field mercury vapor sample analysis system
4. Multi-point sampling, the optional multi-gas sampling device
5. External heat release stove; a copper-like high-speed gas analysis (17 seconds / pcs)
6. External pyrolysis furnace: it can also sample pyrolysis solid
