NBRE-3000B Lab Rotary Evaporator 40W Power 0-180 RPM Rotary Speed Rotary Vacuum Evaporator

Basic Information
Place of Origin: China
Brand Name: NANBEI
Certification: CE,ISO
Model Number: NBRE-3000B
Minimum Order Quantity: 1set
Packaging Details: Wooden cases and cartons
Delivery Time: 7-10days
Payment Terms: TT, LC, Paypal, Western Union, MoneyGram…
Supply Ability: 500 set/per day
Detail Information
Glass Meterial: GG-17 Holder Material: Aluminium Alloy
Pot Shell Material: Aluminium Alloy Collect Flask: 2L 35#
Rotary Speed: 0-180RPM Rotary Power: 40W
High Light:

large rotary evaporator

,

rotary vacuum evaporator


Product Description



NBRE-3000B Lab Rotary Evaporator 40W Power 0-180 RPM Rotary Speed



Features of Lab Rotary Evaporator

Rotators consists of a set of stable and reliable micro motor, speed motor and integrated circuit control device. In the role of electronic speed, it can rotating steadily in 10-180 RPM range, it has reached the advanced level at home and abroad.

1,the move up and down lift system adopts motor revolved lifting structure.

2,the condenser adopted two kinds of optional structure , one is double line convection principle, the other one is a single line with interlayer water, ice, and dry ice container. Used in organic solvent evaporation. And the vertical condenser saves space.

3, the axis of rotation use high temperature high borosilicate glass, heat resistant and good sealing. Sealing parts use teflon + teflon two-way sealing, and the effect is good.

4, it is equipped with heating trough, and built-in resistance wire heater, heating temperature is from room temperature to 99 ℃.

5, the device is equipped with temperature indicator, intelligent temperature controlling, digital display, temperature control implemented by PT100 sensors. When the water temperature reaches primary temperature, the controller automatically cut off the heater power; When is lower than the water, temperature controller automatically turn on the heater power; To realize the tank water temperature be constant.

6, B type, E type is equipped with speed display, can accurately display rotation speed, E type is LCD screens.

NBRE-3000B Lab Rotary Evaporator 40W Power 0-180 RPM Rotary Speed Rotary Vacuum Evaporator 0



Model NBRE-3000A NBRE-3000B NBRE-3000E
Glass meterial GG-17
Holder material aluminium alloy
Pot shell Material aluminium alloy
Pot bravery

Stainless steel

250*130mm

Evaporator flask

3L

Flange mouth:Φ50mm

Collect flask 2L 35#
Rotary speed 0-180RPM
Rotary power 40W 40W Brushless motor
Heating power 1.5KW
Heating temp. 0-99℃
Temp. accuracy -1
Lifting power 15W
Lifting stroke 120mm
Voltage 220/110V 50/60HZ
Dimension 660*420*830
Packing size 630*560*540
Packing weight 30kg
Configuration list
Speed mode No Digital LCD
Speed Display Digital
Temp. display Digital
Temp. control Intelligent temp. control
Sealing method PTFE
Condenser Vertical 100*510
Lifting mode Electric automatic lifting
Continuous feed 19# Standard mouth feed valve
Option
Splash device Transparent cover for heating bath

NBRE-3000B Lab Rotary Evaporator 40W Power 0-180 RPM Rotary Speed Rotary Vacuum Evaporator 1NBRE-3000B Lab Rotary Evaporator 40W Power 0-180 RPM Rotary Speed Rotary Vacuum Evaporator 2
