Hand Held Agricultural Weather Monitor Both AC And DC Power 1 Year Warranty

Basic Information
Place of Origin: China
Brand Name: NANBEI
Certification: CE,ISO
Model Number: NY-SQ
Minimum Order Quantity: 1set
Price: USD1000-USD4000/set
Delivery Time: 7-10days
Payment Terms: TT, LC, Paypal, Western Union, MoneyGram…
Detail Information
Warranty: 1 Year Condition: New
High Light:

agricultural weather monitor

,

water potential meter


Product Description



Hand Held Agricultural Weather Monitor Both AC And DC Power 1 Year Warranty





Brief introduction of Weather monitor :

Hand-held Agricultural Weather Monitor can acquire air temperature,humidity,light intensity,CO2 concentration,dew point,soil temperature,soil moisture and other agricultural envrionmental parameters in real-time.Widely used in facilities agriculture,forestry,horticulture,animal husbandry and other fields,and fulfil to carry out conduct of automatically monitor,automatic control and intelligent management to the facilities for comprehensive agricultural ecological information.



Features of Weather monitor:

Handset :

  1. Small and exquisite,easy to carry and LCD display.
  2. Both AC and DC power are available,convenient for collecting data in field.
  3. Powerful data conservation function:max 12000groups
  4. The data is able to be sent into PC through USB interface.
  5. Power-off memory function : all test data can’t be lost when power cut.
  6. Probes are the same and exchange,different sensors can use other sensor’s probe.Accuracy not affected.
  7. 256 channels : it means one host machine is able to connect max 256 sensors.

Software:

1. Showing the curve trends of each parameter,Max,Min,AVG,Zoom in and out functions.

2. Has the coloring function for overrun area,which is visual display.

3. Be able to change the conservation data into EXCEL to save a copy.

4. Be able to view period of parameter or graph,and can be printed.

5. Completely compatible with 32bit system.



Technical parameter

Testing time≤2s

Recording capacity :12000groups

Recording interval : 1m-99h continuously adjustable

Communication interface : USB,RS-485

Power : 5AA battery,9V/2A power adapter



Hand Held Agricultural Weather Monitor Both AC And DC Power 1 Year Warranty 0

Testing index Parameter Testing index Parameter
Temperature

Range:-40℃~120℃

Accuracy:±0.4℃

Resolution:0.1℃

Rainfall

Range :0~4mm/min

Accuracy:±0.1mm

Resolution:0.1mm

Humidity

Range:0~100%RH

Accuracy:±3%RH

Resolution:1%RH

C02

Range:0~2000ppm

Accuracy:40ppm+Record value ×3%

Resolution:1ppm

Dewpoint

Range:0~100%RH

Accuracy:±3%RH

Resolution:1%RH

Soil temperature

Range:-40℃~100℃

Accuracy:±0.3℃

Resolution:0.1℃;

Illumination

Range:0~200000LUX

Accuracy:±5LUX

Resolution:1LUX

Soil moisture

Range:0~100%

Accuracy:±0.2%

Resolution:0.1%

Radiation

Range:0~2,700μmolm-2s-1(400-700nm)

Accuracy:±1μmolm-2s-1

Resolution:1μmolm-2s-1

PH

Range:pH:0~14

Accuracy:±0.1

Wind direction

Range:0-359°

Accuracy:±1°

Soil salinity

Range:0~100%

Accuracy:±0.2%

Resolution:0.1%

Ammonia

Range:0~10,50,100,200,1000,2000,5000ppm optional

Resolution:0.01ppm(0~100ppm);0.1ppm(0~1000ppm);1ppm(≥1000ppm)

Accuracy:≤±3%

UV radiation

Range:280~400nm(UV AB)

315~400nm(UV A)

280~315nm(UV B)

Sunshine duration

Measure range:0~24h

Spectral range:0.3~3μm

Resolution:0.1h

Respond time:<5s

PM2.5

Range:0.3~1.0,1.0~2.5,2.5~10um

Range : 0~500 ug/m3

Total radiation

Spectral range : 300~3000nm

Signal range : 0~2000W/m2

Air pressure

Range: 0~1100.0HPa

Accuracy: 0.1Hpa

Wind speed

Range : 0-45m/s

Accuracy:±0.1m/s

Net radiation

Spectral range:3~100μm(long wave range);0.3~3μm(shortwave range)

Signal range:0~2000W/㎡

7~14μV/W*㎡

Evaporation

range:0-20mm/day

Accuracy:±1%

Rainfall/Snow

Error:<100ppm

Static power:0.5W
